1 |
Cl. 1.2.1(A)
Minimum air well size |
Cl. 1.4.2 |
To assess if the smaller air well size (10 to 14m) is sufficient for the ventilation of staircase |
2 |
Cl. 2.2.13(a)
Smoke free approach through external exit passageway or external corridor |
Cl. 2.2.13(a) |
To assess if the non-compliance of the following is sufficient for smoke free approach:
|
Cl. 2.2.13(b)(i)(iii)(iv)
Smoke free approach through smoke free lobby |
Cl. 2.2.13(b)(1) to (7) |
3 |
Cl. 2.2.15 (c)
External corridor serving area of refuge |
Cl. 2.2.15(d) |
To assess the deficiency of the external corridor serving the area of refuge |
4 |
Cl. 2.3.2 (c)
External Exit Passageway |
Cl. 2.3.2(c) |
To assess if the non-compliance in the design and ventilation requirement of external exit passageway will affect egress of occupants |
Cl. 2.3.2 (d)
Internal Exit Passageway |
Cl. 2.3.2(d) |
To assess if the non-provision of 15% ventilation opening will affect egress of occupants |
5 |
Cl. 2.3.3 (a) (iii)
Unprotected opening from internal staircase (1.5m horizontally and 3m vertically) |
Cl. 2.3.3(a)(3) |
To assess the effect on the shortfall of the 1.5m horizontal and 3m vertical setback to ventilation opening of internal staircase |
6 |
Cl. 2.3.3 (b) (ii)
Unprotected opening from external staircase (3m horizontally and 3m vertically) |
Cl. 2.3.3(b)(2) |
To assess the effect on the shortfall of the 3m horizontal and vertical setback to external staircase |
7 |
Cl. 2.3.3 (c) (i) (ii) (iii)
Protection at the staircase discharge |
Cl. 2.3.3c. (1) (2) (3) (4) |
To assess the safety at the discharge point if the design deviates from code requirement. |
8 |
Cl. 2.3.3 (f)
Ventilation requirement for exit staircase |
Cl. 2.3.3 d. (7) |
To assess the effect on the shortfall of the 10% ventilation opening on the egress of occupants |
9 |
Cl. 2.4.5 (f)
Smoke free approach to exit staircase for residential occupancy |
Cl. 9.2.1a. (4), (e) & (f) |
To assess the effect on the shortfall of the ventilation width for the smoke free approach:
|
10 |
Cl. 2.4.8
Smoke free approach to exit staircase for residential occupancy via external corridor concept |
Cl. 9.2.1a. (7) |
To access if the non-compliance in the design and ventilation requirement of external corridor will affect egress of occupants |
11 |
Cl. 2.4.13
Common internal corridor – means of ventilation for residential occupancy |
Cl. 9.2.1a. (10), (b) |
To assess the effect on the ventilation for the common internal corridor if the design deviates from code requirement:
|
12 |
Cl. 2.5.1 a (vi), (4) (5) (6)
Internal access corridor to patient accommodation ward |
Cl. 9.3.2 b. (7), (d) (e) (f) |
To assess the effect on the ventilation for the internal corridor if the design deviates from code requirement |
13 |
Cl. 2.5.1 a (vii), (1) & (3)
External corridor to patient accommodation ward |
Cl. 9.3.2 b. (8) |
To assess the effect on the ventilation for the external corridor if the design deviates from code requirement |
14 |
Cl. 2.7.1 (c)
Ventilation requirement for internal corridor (hotels, boarding houses, serviced apartments,
hostels, backpackers hotel) |
Cl. 9.7.2 a. (3) |
To assess the effect on the ventilation for the internal corridor if the design deviates from code requirement:
|
15 |
Cl. 2.7.2
External corridor design (hotels, boarding houses, serviced apartments, hostels, backpackers
hotel) |
Cl. 9.7.2 b. |
To assess the effect on the ventilation for the external corridor if the design deviates from code requirement |
16 |
Cl. 2.9.3 (c) (d) (e)
Ventilation requirement for internal corridor serving workers’ dormitories |
Cl. 9.3.3 e. (3) (4) (5) |
To assess the effect on the ventilation for the internal corridor if the design deviates from code requirement:
|
17 |
Cl. 2.9.4
External corridor serving workers’ dormitories |
Cl. 9.3.3 f. |
To assess the effect on the ventilation for the external corridor if the design deviates from code requirement |
18 |
Cl. 3.2.8 (c) (i) (ii)
Compartmentation requirement for open sided car park |
Cl. 3.2.8a. & b. |
To assess the effect on the compartmentation if the design deviates from code requirement:
|
